| T | L | D | SIZE/mm |
| 1.65 | 38.10 | 25.4 | "1.0 |
| 1.65 | 57.20 | 38.1 | "1.5 |
| 1.65 | 76.20 | 50.8 | "2.0 |
| 1.65 | 95.25 | 63.5 | "2.5 |
| 1.65 | 114.30 | 76.2 | "3.0 |
| 2.10 | 152.40 | 101.6 | "4.0 |
| T | R | L1 | D | SIZE/mm |
| 1.5 | 50 | 50 | 28 | DN25 |
| 1.5 | 55 | 55 | 34 | DN32 |
| 1.5 | 60 | 60 | 40 | DN40 |
| 1.5 | 70 | 70 | 52 | DN50 |
| 2.0 | 80 | 80 | 70 | DN65 |
| 2.0 | 90 | 90 | 85 | DN80 |
| 2.0 | 100 | 100 | 104 | DN100 |
