T | H | E | D | C | B | A | WIDTH,W.T | SIZE/mm |
2 | 12.5 | 20 | 7 | 45 | 60 | 25.4 | 20X2MM | "1 |
2 | 19.5 | 25 | 7 | 62 | 82 | 38.1 | 25X2MM | "1.5 |
2 | 25 | 25 | 7 | 75.5 | 95.5 | 50.8 | 25X2MM | "2 |
2.5 | 32.5 | 25 | 9 | 90 | 112 | 63.5 | 25X2.5MM | "2.5 |
2.5 | 38.5 | 25 | 9 | 104 | 126 | 76.2 | 25X2.5MM | "3 |
2.5 | 49 | 25 | 9 | 130 | 152 | 101.6 | 25X2.5MM | "4 |
3 | 77.5 | 30 | 9 | 185 | 210 | 152.4 | 30X3MM | "6 |
3 | 98.5 | 30 | 9 | 240 | 264 | 203.2 | 30X3MM | "8 |
T | H | E | D | C | B | A | WIDTH,W.T | SIZE/mm |
2 | 7 | 20 | 7 | 30 | 45 | 12 | 20X2MM | DN10 |
2 | 9.5 | 20 | 7 | 36 | 51 | 18 | 20X2MM | DN15 |
2 | 11 | 20 | 7 | 41 | 56 | 22 | 20X2MM | DN20 |
2 | 14 | 20 | 7 | 47 | 62 | 28 | 20X2MM | DN25 |
2 | 16.5 | 20 | 7 | 53 | 68 | 34 | 20X2MM | DN32 |
2 | 20 | 25 | 7 | 64 | 84 | 40 | 25X2MM | DN40 |
2 | 25.5 | 25 | 7 | 76 | 96 | 52 | 25X2MM | DN50 |
2.5 | 36 | 25 | 9 | 97 | 119 | 70 | 25X2.5MM | DN65 |
2.5 | 42.5 | 25 | 9 | 113 | 135 | 85 | 25X2.5MM | DN80 |
2.5 | 49.5 | 25 | 9 | 130 | 153 | 104 | 25X2.5MM | DN100 |
3 | 64 | 30 | 9 | 161 | 186 | 129 | 30X3MM | DN125 |
3 | 77 | 30 | 9 | 186 | 211 | 154 | 30X3MM | DN150 |
